ABB RTA Board PU516A 3BSE032402R1 Real Time Accelerator Module

Pu516a RTA Board

ABB RTA Board PU516A 3BSE032402R1 Real Time Accelerator Module.The analog output module provides an isolated current loop to output its signal level following the sensor. The output circuit is a passive current control element, and the loop voltage can be as high as 40V.

The recommended connections are as follows:

Analog output + 0V + 24V (10V to 40V)

Relay / field interface card

05701-A-0326

05701-A-0327

05701-A-0328

05701-A-0329

The catalytic converter is equipped with analog output module 05701-a-0285. The analog output can be configured as 0-20mA or 4-20mA output mode. Check the configuration table provided with the system to determine the factory configured operating mode.

Operating mode:

You can easily reconfigure ports using a computer connected to a project. For more information, please contact Zellweger analytics or your local agent.

The analog output can be connected to a voltage input device (e.g. A. chart recorder), including and connecting the device input in parallel with a resistor. That is, use a 100 ohm resistor and select an input range of 2V on the chart recorder relay / field interface card remote input connection note that connecting a voltage exceeding 32V to the remote input may cause permanent damage to the single channel control card.
