ABB DI818 3BSE069052R1 32-channels 24 V d.c. Digital Input Module

ABB DI818 3BSE069052R1 32-channels 24 V d.c. Digital Input Module S800 I/O Systems.This module has 32 digital inputs. The input voltage range is 18 to 30 volt d.c. and the input current is 4.3mA at 24 V. The inputs are divided into two individually isolated groups with 16 channels and one voltage supervision input in each group. Every input channel consists of current limiting components, EMC protection components, input state indication LED and optical isolation barrier.

• 32 channels for 24 V d.c. inputs with current sinking
• Two Isolated groups of 16 channels with voltage supervision
• Voltage Supervision
• Signal Filtering

• MTUs that match this product：TU810V1 3BSE013230R1
